Model Number | EUS12IHIBLECCT42300A |
---|---|
Product Group | Smart Linear Driver |
Application Area | Indoor |
Dimming Interface | ZIGBEE, BLE MESH |
Features | 2xCH, Dimable |
Output Power | 12W |
Output Current | 150-300mA |
Output Voltage | 6-42V |
Operating Mode | Constant Current |
Power Factor | HPF |
Type Of Protection | IP20 |
SELV | SELV60 |
Height | 20mm |
Lifetime | 30000h, 50000h |
Powered By | Casambi, Plexilent, Tuya |
Pro Flex 12W 150-300mA EUIX1 – Flicker Free
In stock
Product Description |
|
. | Smart Dimmable Constant Current Driver For Led Modules |
. | Input voltage 240VAC |
. | Output Ripple Current <5% (@ Full Load) – Flicker Free |
. | High efficiency >84%(@100% Load) |
. | Power factor >0.98,THD<10%(@100%Load) |
. | For use in combination with luminaries of protection class II. |
. | Protection against Abnormal Operating Conditions Like Input Over Voltage Protection, Under Voltage Protection, Short Circuit Protection, Open Voltage Protection, Overload Protection |
. | Surge protection 3KV |
. | Compatible with BLE , BLE MESH & ZIGBEE Module |
. | Nominal Life Time: 50,000 hours @ tc ≤ tcmax |
