| Model | EUS12IHIBLECCT42300A |
|---|---|
| Product group | Smart Linear Driver |
| Application area | Indoor |
| Dimming interface | BLE MESH, ZIGBEE |
| Features | 2xCH, Dimmable |
| Output power | 12W |
| Output current | 150-300mA |
| Output voltage | 6-42V |
| Operatiing mode | Constant Current |
| Power factor | HPF |
| Type of protection | IP20 |
| Selv | SELV60 |
| Height | 20mm |
| Lifetime | 30000h, 50000h |
| Powered by | Casambi, Plexilent, Tuya |
Pro Flex 12W 150-300mA EUIX1 – Flicker Free
In stock
Product Description |
|
| . | Smart Dimmable Constant Current Driver For Led Modules |
| . | Input voltage 240VAC |
| . | Output Ripple Current <5% (@ Full Load) – Flicker Free |
| . | High efficiency >84%(@100% Load) |
| . | Power factor >0.98,THD<10%(@100%Load) |
| . | For use in combination with luminaries of protection class II. |
| . | Protection against Abnormal Operating Conditions Like Input Over Voltage Protection, Under Voltage Protection, Short Circuit Protection, Open Voltage Protection, Overload Protection |
| . | Surge protection 3KV |
| . | Compatible with BLE , BLE MESH & ZIGBEE Module |
Application:
Office
Home
Shop
